In the realm of Linux system observability, Extended Berkeley Packet Filter (eBPF) has emerged as a game-changer, offering capabilities that were once thought to be the exclusive domain of kernel space. With eBPF, developers and system administrators can now write programs that run in the kernel space, without changing kernel source code or loading kernel modules, thereby opening up a whole new world of performance monitoring and network traffic analysis. This article delves into the practicalities of using eBPF for system observability, providing you with the knowledge to leverage this powerful tool in your Linux environment.

Understanding eBPF

eBPF stands for Extended Berkeley Packet Filter, an advanced technology that allows users to run sandboxed programs in the Linux kernel without needing to change the kernel code or load modules. It’s an evolution of the original BPF, which was primarily used for filtering network packets. eBPF extends this capability, enabling the analysis of system calls, network traffic, and more, making it an invaluable tool for observability.

Why eBPF for Observability?

The traditional tools for monitoring Linux systems, such as top, iotop, or netstat, offer a surface-level view of what’s happening on the system. In contrast, eBPF provides deep insights into system behavior, including which functions are being called, how network packets are being processed, and how system resources are being utilized. This level of detail is crucial for diagnosing complex performance issues and understanding system behavior under load.

Getting Started with eBPF

To harness eBPF, you’ll need a Linux kernel version 4.x or newer. Most modern distributions should meet this requirement. The bcc tools provide a great starting point for experimenting with eBPF. Here’s how to install bcc on Ubuntu:

1
2

sudo apt-get update
sudo apt-get install bcc-tools libbcc-examples linux-headers-$(uname -r)

A Practical Example: Analyzing Filesystem Activity

One powerful use case for eBPF is monitoring filesystem activity to identify performance bottlenecks or suspicious behavior. The opensnoop tool, part of the bcc collection, is perfect for this task. It leverages eBPF to trace file open calls across the system, showing you which processes are accessing files.

To use opensnoop, simply run:

1

sudo opensnoop

You’ll see a live feed of file open events, including the PID (process ID) and the filename. This can be incredibly insightful for debugging application issues or monitoring for unauthorized access.

Advanced Usage: Custom eBPF Programs

While tools like opensnoop provide out-of-the-box utility, the real power of eBPF lies in writing custom programs. This requires a deeper understanding of the eBPF infrastructure and the C programming language. A simple eBPF program might look like this:

1
2
3
4
5

SEC("tracepoint/syscalls/sys_enter_open")
int trace_open(const struct pt_regs *ctx) {
    bpf_trace_printk("File opened\n");
    return 0;
}

This program uses a tracepoint to hook into the open syscall, printing a message every time a file is opened. While simple, it demonstrates the potential for custom instrumentation of the Linux kernel.

Potential Issues and Troubleshooting

Working with eBPF can be challenging, especially when writing custom programs. Common issues include compatibility problems with older kernels or difficulties in understanding the output. The community around eBPF is growing, and resources like the eBPF.io website and the IO Visor Project can provide invaluable support.

Next Steps and Variations to Explore

Once you’re comfortable with basic eBPF usage, consider exploring more advanced features, such as:

• Creating eBPF maps for storing data across multiple invocations of an eBPF program.
• Using XDP (eXpress Data Path) for high-performance packet processing.
• Leveraging eBPF for security by creating custom intrusion detection systems.

The possibilities with eBPF are vast, and its applications in observability, security, and performance tuning are just beginning to be tapped.

Conclusion

eBPF represents a significant leap forward in the observability and monitoring of Linux systems. By providing the ability to safely execute custom code within the kernel, it offers insights and capabilities that were previously difficult or impossible to achieve. Whether you’re diagnosing performance issues, analyzing network traffic, or implementing custom security solutions, eBPF has become an indispensable tool in the modern Linux toolkit.

Embrace the power of eBPF and unlock a new level of system observability and control. Happy hacking!
